Name: Load Cell Sensor MT1241 150kg – Industrial Grade Weighing Sensor with 2m Wire
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Célula de carga MT1241-150kg 2m
Availability: InStock

Inicio Productos

Load Cell Sensor MT1241 150kg – Industrial Grade Weighing Sensor with 2m Wire

Datos del producto:

Lugar de origen:	China
Nombre de la marca:	Mettler Toledo
Número de modelo:	Célula de carga MT1241-150kg 2m

Pago y Envío Términos:

Cantidad de orden mínima:	1 Conjunto
Precio:	Negociable
Detalles de empaquetado:	Caja de cartón
Tiempo de entrega:	10-30 días
Capacidad de la fuente:	2000 juegos por mes

Contacto

Descripción detallada del producto

Producto:	Mettler Toledo Celular de carga	Capacidad Máxima:	330 lb (150 kg)
Material:	Aluminio, pasivado	Metrología:	NTEP III 5,000d OIML C3
Precisión:	Estándar	Calificación de protección:	Protección IP67
Tamaño de la plataforma (La x An):	400 mm x 400 mm	Conectividad:	Análogo
El cable:	6.6 pies (2 m)
Resaltar:	MT1241 load cell sensor 150kg , industrial grade weighing sensor , load cell with 2m wire

Load Cell Sensor MT1241 150kg – Industrial Grade Weighing Sensor with 2m Wire

High-Performance Compression Weigh Module

This compression weigh module features top and base plates that compress under load, designed for direct installation on ground, piers, or structural beams. Ideal for large platform scales including truck and railroad track scales, as well as tank, hopper, and silo weighing applications.

Key Features

High-performance single point load cell with off-center compensation
Standard metrology approvals including OIML
Premium aluminum construction with strain gauge technology for durability
ATEX Zone 1/21/2/22 approvals included as standard
IP67 protection rating for harsh environments

Technical Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	330 lb (150 kg)
Material	Aluminum, passivated
Material Number	71201841
Metrology	NTEP III 5,000d OIML C3
Accuracy	Standard
Protection Rating	IP67
Platform Size (LxW)	400 mm x 400 mm
Connectivity	Analog
Cable	6.6 ft (2 m) PVC

Ideal Applications

Perfect for mid-size platform scales in industrial environments. The robust design and hazardous area certifications make it suitable for demanding weighing applications in manufacturing, logistics, and process industries.
