Name: The Ultimate Guide to Choosing the Right Check Scale
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: La guía definitiva para elegir la balanza de cheque adecuada
Availability: InStock

Inicio Productos Controlador de peso automático

The Ultimate Guide to Choosing the Right Check Scale

Datos del producto:

Lugar de origen:	China
Número de modelo:	La guía definitiva para elegir la balanza de cheque adecuada

Pago y Envío Términos:

Cantidad de orden mínima:	1 juego
Precio:	Negociable
Detalles de empaquetado:	Caja
Tiempo de entrega:	10-30 días
Capacidad de la fuente:	2000 establecido por mes

Contacto

Descripción detallada del producto

Producto:	La guía definitiva para elegir la balanza de cheque adecuada	Capacidad máxima:	3 kg, 15 kg, 60 kg, 300 kg
Legibilidad / Graduación (d):	0.1 g, 1 g, 5 g, 50 g	Capacidad mínima:	Típicamente 10 veces la legibilidad.
Clase de precisión:	Clase I, II, III y IIIII	Certificación:	NTEP (U.S.), OIML (International), CE
Tamaño de la plataforma:	Las medidas de ensayo se aplicarán en el caso de los vehículos de las categorías M1 y M2	Material de las plataformas:	Acero inoxidable, Acero dulce, Plástico ABS
Tipo de visualización:	LCD (Pantalla de cristal líquido), LED (Diodo emisor de luz)	Clasificación IP (protección contra la entrada):	El valor de las emisiones de gases de efecto invernadero es el valor de las emisiones de gases de ef
Fuente de alimentación:	Adaptador de CA, Batería recargable, Pilas secas
Resaltar:	check weighing for food industry , pharmaceutical check weighing scales , Mettler Toledo load cell scales

The Ultimate Guide to Choosing the Right Check Scale

A check scale (also known as a weighing scale) is a vital piece of equipment for many industries, from logistics and manufacturing to retail and agriculture. Choosing the right one ensures accurate measurements, improved efficiency, and compliance with regulations. This guide will walk you through the essential factors to consider and provide a detailed parameter table to help you make an informed decision.

Key Factors to Consider

1. Capacity and Readability:

Capacity: This is the maximum weight the scale can handle. It's crucial to choose a scale with a capacity greater than the heaviest item you'll be weighing. Overloading a scale can damage it and lead to inaccurate readings.
Readability (or Graduation): This is the smallest increment the scale can measure. For example, a scale with a readability of 1g can display weight in 1-gram increments. High readability is essential for weighing small, precise items, while lower readability is acceptable for heavier, less critical items.

2. Accuracy and Legal-for-Trade Certification:

Accuracy: This refers to how close the scale's measurement is to the true weight of the item. All scales have a degree of error, and a good quality scale will have a low margin of error.
Legal-for-Trade: If you're using the scale for commercial purposes where the weight determines the price of a product (e.g., selling produce, shipping packages), the scale must be "legal-for-trade" or "NTEP certified" (in the U.S.). These certifications ensure the scale meets specific government standards for accuracy and reliability.

3. Platform Size and Construction:

Platform Size: The size of the weighing platform should be large enough to comfortably hold your typical items without obstructing the display or controls.
Construction Material: Scales are typically made from stainless steel, mild steel, or plastic. Stainless steel is durable, corrosion-resistant, and easy to clean, making it ideal for food processing or harsh environments. Mild steel is a cost-effective option, often used in dry warehouses. Plastic is lightweight and suitable for light-duty applications.

4. Environment and Durability (IP Rating):

Environment: Consider where the scale will be used. Will it be exposed to dust, water, or extreme temperatures?
IP (Ingress Protection) Rating: This rating indicates how well the scale is protected against solids and liquids. For example, an IP65 rating means the scale is dust-tight and protected against water jets. An IP68 rating means it's fully protected against dust and can be submerged in water.

5. Connectivity and Features:

Connectivity: Modern scales often come with various connectivity options, such as USB, RS-232, Ethernet, or Wi-Fi. This allows the scale to interface with computers, printers, and other systems.
Features: Look for features that will improve your workflow, such as tare function, counting function, checkweighing, backlit display, and battery operation.

Specifications

Parameter	Specifications
Maximum Capacity	3 kg, 15 kg, 60 kg, 300 kg
Readability / Graduation (d)	0.1 g, 1 g, 5 g, 50 g
Minimum Capacity	Typically 10x the readability.
Accuracy Class	Class I, II, III, IIII
Certification	NTEP (U.S.), OIML (International), CE
Platform Size	250x300 mm, 400x500 mm, 600x800 mm
Platform Material	Stainless Steel, Mild Steel, ABS Plastic
Display Type	LCD (Liquid Crystal Display), LED (Light Emitting Diode)
IP Rating (Ingress Protection)	IP65, IP67, IP68
Operating Temperature	-10°C to +40°C
Interfaces/Connectivity	RS-232, USB, Ethernet, Bluetooth, Wi-Fi
Weighing Functions	Tare, Counting, Checkweighing, Accumulation
Stabilization Time	1-3 seconds

etiqueta:

Persona de Contacto: Mrs. Shirley

Teléfono: +86-15851932889

Fax: 86-519-68781609

Otros productos

C35 AdvancedLine Checkweigher for Ultimate Production Efficiency

Producto: C35 Pesador de comprobación avanzado

Aplicación de inspección: Comprobación de verificación de peso de verificación

Industria: Componentes químicos, alimenticios y bebidas de metal, plástico y electrónica

Precisión de peso: desde ±0.01 g

Checkweigher Combinations with Vision Systems

Producto: Combinaciones de controlador con sistemas de visión

Cámaras: 2-8X CMOS industrial (5-20MP)

Óptica: Lentes telecéntricas (aumento de 0.1-0.5x)

iluminación: Matrices de LED de ángulo múltiple (RGB/W/UV/IR)

Industrial Weight Checkers Ensuring Product Compliance & Accuracy

Producto: Verificadores de peso industrial

Ancho del cinturón: 150-800 mm (ajustable)

Material de correa: PU, PVC o metal detectable

Velocidad del cinturón: 5-120 m/min (servocontrolado)

Checkweigher Integration in Packaging Lines

Producto: Integración de checkwheigher en líneas de embalaje

Ancho del transportador: 200–1200 mm

Sincronización de la velocidad del cinturón: 5–120 m/min

Espaciado de productos: Mínimo 50 mm entre artículos

Pharmaceutical-Grade Automated Checkweighers for cGMP Compliance

Producto: Charmacéuticos de cheques automatizados de grado farmacéutico

Rango de pesaje: 0.1mg - 500 g (personalizable hasta 5 kg para volumen)

Legibilidad: 0.1mg (modelos de micro balance), 1 mg (estándar)

Exactitud: ± 0.1mg a ± 5 mg (dependiendo del modelo)
